The world’s smallest and lightest 20,000-lumen projector.



Specifications

Projection System: High-aperture Epson® 3LCD, 3-chip technology

Projection Method: Front/rear/ceiling mount

Driving Method: Poly-silicon TFT Active Matrix

Pixel Number: 2,304,000 dots (1920 x 1200) x 3

Signal Input Maximum Display Resolution: 4096 x 2160 (resizing display) Display Resolution: 1920 x 1200 pixels

Native Resolution: WUXGA with 4K Enhancement (1920 x 1200 x2)

Resolution on Screen: WUXGA with 4K1 Enhancement/4.6 million pixels

Aspect Ratio Supports: 4:3, 16:9, 16:10

Pixel Arrangement: Cross stripe

Color Brightness: Color Light Output: 20,000 lumens

White Brightness: White Light Output: 20,000 lumens

Contrast Ratio: 2,500,000:1 (Dynamic Contrast: On)

Lamp Hours: 20,000 hours

Brightness Uniformity (typical): 85%

Color Reproduction: Up to 1.07 billion colors

Len Shift: Vertical: ±60 degrees; Horizontal: ±18 degrees

Keystone Correction: Vertical: ±45 degrees; Horizontal: ±30 degrees

Illumination Technology: Laser Diode

 Projection Lens (Standard)

Standard Lens: ELPLM15 (sold separately)

Type: Powered shift/focus/zoom

F-number: 2.0 – 2.1

Focal Length: h 14.8 mm – 17.7 mm

Zoom Ratio: Optical zoom 1.0 – 1.6x

Throw Ratio Range: 1.57 – 2.56

Lens Shift: ±60 degrees; Horizontal: ±18 degrees

Other Features

Operating Temperature: 32 ˚ to 113 ˚F (0 ˚ to 45 ˚C)

Power Supply Voltage: 100 – 240 V ±10%, 50/60 Hz AC

Power Consumption: 1,301 W (Normal / Custom)

899 W (Quiet / Extended)

2.0 W Standby (Network Standby)

0.4 W Standby (Energy Saving)

Fan Noise: 45dB (Normal Mode)

                    37dB (Eco Mode)

IP Rating: IP5X

Security: Security cable hole, lens lock, Kensington lock provision, wireless LAN unit lock

Video I/O

Input Signal: Input Video Signal (HDMI, DVI-D and HDBaseT ports) 480i/480p/576i/576p/720p/1080i/1080p/3840 x 2160/4096 x 2160

Dimensions (W x D x H)

Excluding Feet, Lens: 23.1" x 19.4" x 8.6"

Weight: 53.7 lb (24.4 kg)

Remote Control

Features: Power; Source Search Selection; Lens Shift/Zoom/Focus; Test Pattern Selection; A/V Mute, Freeze, User ID, AutoAspect, Color Mode, Number, Page Up and Down, E-Zoom,Volume, Help, Menu, Enter, ESC and Pointer Functions

Operating Angle: Front: Right/Left: 60 to +60°; Upper/Lower: +30 to

30°

                                Rear: Right/Left: 30 to +30°; Upper/Lower: +40 to +10°

Operating Distance: 98 ft

Eco Features

RoHS compliant

Recyclable product

Epson America, Inc. is a SmartWay® Transport Partner

Support

Epson ConnectionSM

Pre-sales support U.S. and Canada 800-463-7766

Internet website www.epson.com

Service Programs

The projector has a limited warranty of 3 years.

What’s in the Box

EB-PU2220B projector, power cable, remote control with two batteries, cable cover, user guide and warranty sheet
