OVERVIEW

Model Number

JM-CCWM-AC-16

Product Type

Multi-Device Charger

Functions

Charge/Storage

Max Power

110V/220V@ Max 16A

Slot Number

16 bays

Device Compatibility

Chromebook / Tablet / iPad / iPhone

Shelf Number

1

Lock Type

Key

Product Specs

40”(H) x 25”(W) x 18“(D) | 125.5 lbs

46cm (H) x 63.3cm (W) x 48.5cm (D) | 25 kgs

Bay Specs

11” (H) x 1.1” (W) x 16” (D)

28.2cm (H) x 3cm (W) x 43.4cm (D)

16 Bays per cart

Bay Power

One (1) PD 3.0 USB-C port

5-15Vac 3A Max One (1) 18W USB-C Power Delivery port per bay

Available output power range: 5V 3A | 9V 2A | 12V 1.5A | 15V 1.2A

Bay Access

PD 3.0 USB-C port

Type C to X charging cable

Number of Charging Ports

16

Cart Input Power Specs

100-250V

50/60Hz (auto-select)

16A Max

Input Plug Type

C13 to Country plug

Input Cord Length (m)

2.6 meter

Cart Output Power Specs

5-24Vac 350W as Max per shelf

Construction System

Built-In Circuit Breaker

Flow-Through Ventilation

Cord Management

3-point Locking System

Powder-coated steel with 1.2mm thickness

Protection System

Over-charge Protection

Over-current Protection

Auto Cooling System

Warranty

2 Years Limited Warranty on main frame,

1 Year Limited electrical and all other components

Certifications Approvals

Tested to ETL, CCC, CE, Rohs

Optional Accessories

Mechanical Lockers

Smart Digital Locker

Padlock Kit

USB-C to C charging cable

USB Type C to Lightning charging cable

Handle & Caster Kit

UV Sterilization Kit

Wall-mount Kit

SMT Charging Management System

AC Time Charging Management System

Universal Key

1 locker 1 Key

20000 mah 65W Laptop Power Bank Kit

White/Orange/Black/Blue/Green as paint optional
