OVERVIEW

Model Number

JM-CCF-H-AC-32

Product Type

Multi-Device Charger

Functions

Charge/Secure/Storage

Max Power

depends on the different country standard

Slot Number

32 bays

Device Compatibility

Chromebook / Tablet / iPad / iPhone

Shelf Number

2 Shelves

Lock Type

Key

Product Specs

40”(H) x 25”(W) x 23“ (D) | 187 lbs

101.3cm (H) x 64.5cm (W) x 57.8cm (D) | 85 kgs

Bay Specs

10” (H) x 1” (W) x 16.4” (D)

25.4cm (H) x 2.6cm (W) x 41.6cm (D)

32 Bays per cart

Bay Power

100 – 250V as different country

50 – 60Hz (auto-select)

Max.16A

Bay Access

Adapter

Charger with different types of cable

Number of Charging Ports

32

Cart Input Power Specs

100-250V

50/60Hz (auto-select)

16A Max

Input Plug Type

C13 to Country plug

Input Cord Length (m)

3.5 meter

Cart Output Power Specs

100-250Vac

50/60Hz (auto-select)

16A Max

Construction System

Built-In Circuit Breaker

Flow-Through Ventilation

Cord Management

3-point Locking System

Powder-coated steel with 1.2mm thickness

Protection System

Over-charge Protection

Over-current Protection

Auto Cooling System

Warranty

2 Years Limited Warranty on main frame,

1 Year Limited electrical and all other components

Certifications Approvals

Tested to ETL, CCC, CE, Rohs

Optional Accessories

Mechanical Lockers

Smart Digital Locker

Padlock Kit

USB-C to C charging cable

USB Type C to Lightning charging cable

Handle & Caster Kit

UV Sterilization Kit

Wall-mount Kit

SMT Charging Management System

AC Time Charging Management System

Universal Key

1 locker 1 Key

20000 mah 65W Laptop Power Bank Kit

White/Orange/Black/Blue/Green as paint optional
